SPT Series 15–25kW On-Grid PV Inverter
The SPT Series (15–25kW) is a high-performance, three-phase solar inverter designed for medium-scale commercial and industrial PV systems. Built for on-grid applications, it offers exceptional energy efficiency, intelligent MPPT control, and long-lasting durability, making it perfect for medium-sized solar installations. Equipped with dual MPPT trackers, the SPT Series maximizes energy harvest from your solar array—even in partially shaded conditions. Its wide MPPT voltage range (480–850V) and high input voltage (1,100VDC) provide flexibility in system design and allow for oversizing up to 150%. With a peak efficiency of 98.75%, the inverter reduces energy loss and enhances your return on investment. Housed in a rugged IP65-rated enclosure, the SPT inverter is suitable for outdoor installations and operates in extreme conditions, from -30°C to +60°C. It also features built-in USB/RS485 communication and optional WiFi/GPRS modules, enabling seamless remote monitoring and management via a mobile app or PC. Whether you're powering a commercial rooftop, industrial facility, or distributed solar plant, the SPT Series combines advanced technology with robust design to ensure long-term performance, reliability, and energy savings.
- 2-year warranty
- Worldwide support
- Certified & compliant
Configure your model
Select every option to reveal the matching model.
Specifications
- Rated AC Output Power (On-grid)
- —
- Max PV Input Voltage
- 1,100 VDC
- MPPT Voltage Range
- 480V–850V
- Max Input Current
- 15A*2
- Max PV input power
- —
- Rated AC Output Voltage (On-grid)
- 380VAC/400VAC
- Grid Type
- On-Grid
Highlights
- High power density and long life components, stable and reliable.
- IP65 Protection, supporting outdoor installation.
- Dual MPPT inputs, maximum 150% DC input oversizing.
- Maximum DC input voltage of 1,100VDC, maximum string input current of 15A.
- Support 110% long term overload.
- Optional GPRS and WiFi modules for remote monitoring.
- DC Type II & AC Type SPD to prevent lightning damage.
- Support anti-backflow function(optional).
