DUC Series 12V DC-DC Battery Charger 30A/40A/50A
The DUC Series DC-DC Battery Charger is designed to efficiently charge service batteries from vehicle alternators while protecting battery health and maximizing charging performance. With advanced MPPT-inspired charging algorithms and multi-stage charging control, the DUC Series ensures safe and reliable charging for both lithium and lead-acid battery systems. Whether installed in RVs, camper vans, boats, commercial vehicles, or off-grid energy systems, the DUC charger delivers stable power conversion and intelligent battery management.
- 2-year warranty
- Worldwide support
- Certified & compliant
Configure your model
Maximum Charging Current
Rated Voltage
Maximum Output Power
Select every option to reveal the matching model.
Specifications
Model: DUC5011
Electrical Parameters
- Rated Voltage
- 12V-12V
- Input Voltage Range
- 9-17V
- Maximum Input Voltage
- 17V
- Output Charging Voltage Range
- 10-17V
- Input/Output Current Range
- 1-50A
- Max. Output Power
- 700W
- Max. Efficiency
- ≥98.1%
- Standby Current Losses
- 11mA
- Commnunication Method
- CAN(RV-C Protocol)/RS485 (5VDC/300mA)
- Operating Temperature
- -20°C to +60°C (>40℃ derating)
- Altitude
- 2000m
- Relative Humidity
- ≤ 95% (N.C.)
- Ingress Protection
- IP32
- Dimensions (L × W × H) (mm)
- 191mm x 181mm x 76.5mm
- Weight
- 1.45kg
Highlights
- Multiple operating modes for different application scenarios
- Generator start-stop detection logic for enhanced generator energy efficiency
- Supporting multiple generator types, including smart/Euro 6 generators
- Conversion efficiency up to 98.1%
- Multi-stage charging curve algorithm
- House battery supports various battery types, including lithium batteries
- Stable self-activation for lithium batteries
- eDuallimits for input and output power, and current
- Protection level IP32 Natural cooling for heat dissipation, and low-noise operation
- RS485/CAN communication
- Comprehensive electronic protections
- Energy statistics
- Compliant withlEC62477-1, EMC, and other relevant standards
